Sunex Tools 5000A - Parts List

5000A 5 rev. 11/04/13
1 Base 1
2 Washer 4
3 Bolt 4
4 Column Support 1
5 RS5000A05 Rack 1
6 RS5000A06 Rack Collar 1
7 Screw 1
8 RS5000A08 Table Support w/Indicator 1
and incl. #'s 9, 10, 18, & 19
9 Crank 1
10 Bolt 1
11 Gear Pin 1
12 Washer 1
13 Bolt 1
14 Table Clamp 1
15 RS5000A15 Table Arm 1
16 Table 1
17 Column Clamp 1
18 Helical Gear 1
19 Worm 1
20 Knob 3
21 RS5000A21 Handle Bar with #20 Knob 3
22 Feed Shaft 1
23 Cylinder Bolt 1
24 Depth Stop Ring w/Scale 1
25 Pinion Shaft 1
26 Head 1
27 Screw 1
28 Nut 1
29 RS5000A29 Tension Spring with #30 Cap 1
30 Spring Cap 1
31 Nut 2
32 Depth Screw Lock/Indicator 1
33 Screw 2
34 Belt Tension Handle 1
35 Motor Adjusting Knob 2
36 Motor Bracket Support 1
37 Bolt 4
38 Washer 4
39 Motor Mount 1
40 RS5000A40 Motor 1
41 Elastic Washer 4
42 Nut 4
43 Nut 2
44 Washer 2
45 Power Plug Cord 1
46 Motor Bracket Support 1
47 Bolt 1
48 Clamp Nut Cap 2
49 Adjusting Lever 1
50 Clamp 2
51 Screw 2
52 Switch Washer 1
53 RS5000A53 Switch 1
54 Screw 2
55 Cord Clamp 1
56 Screw 1
57 Washer 4
58 Screw 4
59 RS5000A59 Motor Pulley 1
60 Screw 1
61 Pulley Cover 1
62 Adjusting Pulley 1
63 Knob 1
64 RS5000A64 Center Pulley 1
65 RS5000A65 V-belt 1
66 RS21109 Ball Bearing 2
67 Retaining Ring 1
68 Screw 2
69 Washer 2
70 RS5000A70 V-Belt 1
71 Nut 1
72 RS5000A72 Spindle Pulley 1
73 Pulley Insert 1
74 Retaining Ring 1
75 RS50528 Ball Bearing 1
76 Spacer 1
77 RS50528 Ball Bearing 1
78 Retaining Ring 1
79 Axle Shield Ring 1
80 RS5000A80 Ball Bearing
81 Washer 1
82 Guide Tube 1
83 RS5000A83 Drill Key 1
84 RS50528 Ball Bearing 1
85 RS5000A85 Spindle (incl. #86) 1
86 Arbor 1
87 RS5000A87 Chuck & Key 1
88 Column Base 1
IndexNo. PartNo. Description Qty.
IndexNo. PartNo. Description Qty.
5000A
16 Speed Drill Press
Parts List
