6622A 6 rev. 05/05/11
PARTS LIST
MODEL 6622A
CAPACITY: 22 TON
AIR/HYDRAULIC TRUCK JACK
Index# Part# Description Qty
Index# Part# Description Qty
1-1 Right Frame Assy. 1
1-2 Washer 4
1-3 Screw 4
1-4 Washer 4
1-5 Bolt 4
1-6 Washer 4
1-7 Screw 4
1-8 Washer 4
1-9 Bolt 4
1-10 RS22A110 Wheel 2
1-11 RS22A111 Washer 2
1-12 Bracket 1
1-13 Left Frame Assy. 1
1-14 Bracket 1
1-15 RS22A115 Universal Joint Assy. 1
1-16 Pin 2
1-17 RS22A117R Handle Socket 1
1-18 RS22A118 Screw 1
1-19 RS22A119R Cover 1
1-20 Washer 4
1-21 Washer 4
1-22 Washer 1
1-23 Washer 1
1-24 Washer 1
1-25 Screw 1
1-26 Rod Joint 1
2-1 RS22A21R Spring Hanger 1
2-2 Washer 1
2-3 Washer 2
2-4
*
O-ring 1
2-5 RS22A25 Piston Rod Assy. (incl. 2-2 to 2-10) 1
2-6
*
Piston Ring 1
2-7
*
Sealing Washer 1
2-8
*
O-ring 1
2-9
*
Washer 1
2-10
*
Washer 1
2-11
*
Oil Filler Plug 1
2-12 Body
2-13 Screw 3
2-14 O-ring 3
2-15 RS22A215 Spring
3-1 Valve Block Assy. 1
3-2
*
Steel Ball 2
3-3
*
Spring 1
3-4
*
Steel Ball 1
3-5
*
Spring 1
3-6
*
Copper Washer 1
3-7 Screw 1
3-8
*
Steel Ball 1
3-9
*
Ball Seat 1
3-10 Spring 1
3-11 Screw 1
3-12
*
Sealing Gasket 1
3-13 Screw 1
3-14 Sealing Washer 1
3-15 RS22A315 Release Valve Rod (incl. 3-2, 3-14, 3-15) 1
3-16 Pin 1
4-0 RS22A40R Air Pump Assy. 1
4-1
**
Copper Washer 1
4-2 Pump Cylinder 1
4-3
**
Oil Seal 1
4-4
**
Nylon Gasket 1
4-5
**
Copper Bushing 1
4-6 Nut 1
4-7 Screw 8
4-8 Front Cover 1
4-9 Air Pump Housing 1
4-10 Nut 1
4-11 Spring 1
4-12 Washer 1
4-13 Cylinder Pump Plunger 1
4-14 Piston Body "A" 1
4-15
**
O-ring 2
4-16 Air Release Rod 1
4-17
**
O-ring 2
4-18 Piston Body "B" 1
4-19 Screw 3
4-20
**
Air Seal 1
4-21
**
O-ring 2
4-22
**
O-ring 1
4-23 Rear Cover 1
4-24 Steel Ball 4
4-25 O-ring 3
5-0 RS22A50 Handle Assy. 1
5-1 RS22A51 Knob (incl. 5-1, 5-2) 1
5-2 Pin 1
5-3 Sleeve 2
5-4-1 Front Handle 1
5-4-2 Rear Handle 1
5-5 Screw 1
5-6 Bushing 1
5-7 Control Rod A 1
5-8 Pin 4
5-9 Strap 1
5-10 Spring 1
5-11 Washer 1
5-12 Bushing 2
5-13 Screw 2
5-14-1 Convey Rod A 1
5-14-2 Convey Rod B 1
5-15 RS22A515 Control Rod B (incl. 5-8,5-15, 5-16) 1
5-16 Pin 1
5-17 Washer 2
5-18 Screw 2
6a RS22A6A Air Valve Assembly 1
6b RS22A6B Hose 1
7-1 RS22A71BK Adapter D (48 x 100) 1
7-2 RS22A72BK Adapter C (48 x 50) 1
7-3 RS22A73BK Adapter B (48 x 20) 1
7-4 Nut 4
7-5 Washer 4
7-6 Washer 4
7-7 RS22A77BK Bracket Assy. (incl. 4ea. 7-4, 7-5, 7-6,
3ea. 7-8, 7-11
2ea. 7-9
1ea. 7-7) 1
7-8 Pin 3
7-9 Bolt 2
7-10 RS22A710BK Adapter A (68 x 20) 1
7-11 Ring 3
RS6622ALK Product Label Kit (not shown) 1
*
Available in RS22AHRK- Hydraulic Repair Kit
**
Available in RS22APRK - Air Pump Repair Kit
Only numbers identified by Part No. are available separately.
