Troubleshooting...
Otherfactorsoutsidethetoolmaycauselossofpowerorerratic
action.Reducedcompressoroutput,excessivedrainontheairline,
moistureorrestrictionsinairpipesortheuseofhoseconnectionsof
impropersizeorpoorconditionsmayreduceairsupply.Gritorgum
depositsinthetoolmaycutpowerandmaybecorrectedbycleaning
theairstrainerandflushingoutthetoolwithgumsolventoiloran
equalmixtureofSAE#10andkerosene. Ifoutsideconditionsare
inorder,disconnect toolfrom hoseand taketooltoyour nearest
authorizedservicecenter.
Operation...
Letthetooldothework.Donotputextremepressureonthe
machine.Thiswillonlyslowdownthespeedofthecuttingwheel,
reducecuttingefficiency,andputanadditionalburdenonthe
motor.Startthetooloffthework,setitdownontheworkevenly
andmoveinthedirectiondesiredtomakethecut.Whenfinished
cutting,liftofftheworkbeforestoppingthemotor.
NOTE:Duringoperation,safetygogglesshouldalwaysbeworn
toguardagainstflyingrustandchips.Useonlywheelsratedat
25,000RPMorhigher.
Air Supply...
Tools of this class operate on a wide range of air pressures. It is
recommendedthatairpressureofthesetoolsmeasures90PSIatthe
toolwhilerunningfree.Higherpressure(over90psig;6.2bar)raises
performancebeyondtheratedcapacityandwillshortentoolandcan
causeaccessoryfailureduetooverspeed.
Alwaysuseclean,dryair.Dust,corrosivefumesand/orwaterintheair
linewillcausedamagetothetool.Draintheairtankdaily.Cleanthe
airinletfilterscreenonatleastaweeklyschedule.Therecommended
hookupprocedurecanbeviewedinfigure1.
Lubrication...
Lubricatetheairmotordailywithqualityairtooloil.Ifnoairlineoiler
isused,run1/2ounceofairtooloilthroughthetoolbysquirtingoil
intothetool'sairinletorintothenearestconnectiontotheairinlet,
reconnectingairsupply,andthenrunningtool.Donotusemorethan
1/2ounceofoil,asoverfillingwillreducetheperformanceofthetool.
