Sunex Tools SX264 - Parts Breakdown

SX264 3 Rev. 6/16/20
PART DESCRIPTION REF.
NO. NO.
RS26401A Motor Housing Assembly 1-16
RS26402A Air Motor Assembly 17-27
RS26403A Angle Head Assembly 26, 30-35
RS26428 Connect Nut 28
RS26429 Clamp Nut 29
RS26437 1/4" Collet 37
RS26438 Collet Nut 38
RS26439 Wrench 39
RS26440 Wrench 40
RS26441 Air Inlet 41
SX264
1/4" MINI RIGHT ANGLE
DIE GRINDER
