User's Manual
21
CHAPTER 2
Tape Player connections
The tape player’s output can
be connected to the TAPE or DAT
inputs. If you have two players, the
TGR-3 will au to mat i cal ly select the
input which has a signal present. The
unused deck must be turned off when
the other deck is playing.
The tape player can record the au-
dio from whichever source is selected,
but not from DAT to TAPE, or TAPE
to DAT. Use an external switchbox to
dub recordings.
play
record
Analog audio signals (play)
From: Tape player audio outputs
To: TGR-3 Tape L/R audio inputs
Analog audio signals (record)
From: TGR-3 Tape L/R audio
output
To: Tape Player L/R audio
input
