Sunfire X24 - Open Top Burners

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 25
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
OPEN TOP BURNERS
ITEM PART # DESCRIPTION
OPEN TOP SECTION
CRITICAL
12" 24" 36" 60"
1 4522264 Dual Venturi Housing Base Assembly 1 2 3 5
3 4522266 Air Shutter - Open Top 2 4 6 10
4 F43 10-24 x 3/8" Hex Washer Head Screw 2 4 6 10
5 4523090 Open Top Burner Rest 1 2 3 5
6 4522273 Burner Head - Sunre 2 4 6 10
7 4522296 Top Grate - Sunre 2 4 6 10
8A 26878XX
Open Burner Valve, no Hood
Note: Used UP TO (date) 2-May/12 (model) G36-6R-0005 /
U36-6C-0014 (serial#) 1204100101467 / 1204100101482
2 4 6 10 C
8B 4530671
Open Burner Valve, no Hood
Note: Used FROM (date) 2-May/12 (model) G36-6R-0005 /
U36-6C-0014 (serial#) 1204100101467 / 1204100101482
2 4 6 10 C
10
M838 Sunre Open Top Orice Natural Gas #38 2 4 6 10 C
M853 Sunre Open Top Orice Propane Gas #53 2 4 6 10 C
11 4522585 Knob - Sunre 2 4 6 10 C
15 1086597 Pilot Gum Valve 1 2 3 5
16 4523127 Open Top Pilot Tube Assembly 1 2 3 5
17 4522401 Crumb Tray 1 2 3 5
18 4522403 Crumb Tray Trim 1 2 3 5
19 CK4523335 Crumb Tray Assembly - Sunre 1 2 3 5
20 F554 Rivet .125" Dia. SS 2 4 6 10
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
