Sunfire X24 - 24-Inch Space Saver Oven; Cabinet Door

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 8
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
24" SINGLE SPACE SAVER OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
1 4523184 24" Main Channel Front 1
2 4525529 24" Main Channel Rear 1
3 4522764 Body Side L/R 2
4 4523041 Main Back 24" Oven 1
5 4522762 Flue Riser Std Oven 1
6 4524626 24” Veneer Back, S/S
7 4522787 Oven Pilot Assembly (on L/H Side of Burner) 1 C
8 4522900 Oven Pilot Bracket, Sunre 1
9* F440 #10 - 32 x 1/4" Screw 2
10 2200706 Thermocouple Retaining Nut 1 C
12 2200704 3/16" Compression Nut - Oven Pilot 1 C
13 2200705 3/16" Ferrule - Oven Pilot 1 C
14 4523506 Thermocouple Oven 60" 1 C
15A 4522899
Oven Burner Bracket
Note: Used FROM (serial#) 0903100100769.
1 22MAR/09
15B 4522983 Oven Burner Bracket, Sunre 1 22MAR/09
15C 4512234 Burner Bracket Guide 22MAR/09
17
2200702 Pilot Orice #32 Natural Gas 1 C
2200703 Pilot Orice #23 Propane 1 C
18
M940 Large Orice # 40 Natural Gas 1 C
M952 Large Orice # 52 Propane 1 C
19A 14155XX Oven Orice Fitting (without orice) 1 C
19B
1415540F Oven Orice Fitting with #40 Hood (Natural) 1 C
1415552F Oven Orice Fitting with #52 Hood (Propane) 1 C
20 4522781 Orice Bracket - Oven 1
21 1028100 Steel Oven Burner with Air Shutter 1
25 4525152 Sunre 20W Oven Door Assembly 1
26 4524059 Door Frame Assembly 20W Sunre 1
27 1082500 Oven Door Trunion 2
28 4523336 Oven Door Panel 20W Sunre) 1
29 4522378 Oven Door Liner 20W 1
30 4524061 Insulation Door 20W 2
31A 3010000
Door Handle End Insulator - Type 1
Note: Use Kit 4526108 (item 33C).
2 14AUG/08
31B 4524911
Door Handle End Insulator - Type 2
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
2 15AUG/08
32A 3007300
Door Handle End - Type 1
Note: Use Kit 4526108 (item 33C).
2 14AUG/08
32B 4524910
Door Handle End - Type 1
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
2 15AUG/08
33A 4524987
Door Handle 20W, Sunre, 1.0” Dia, Type 1
Note: Use Kit 4526108 (item 33C).
14AUG/08
33B 4522647
Door Handle 20W, Sunre, 1.0” Dia, Type 2
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
1 15AUG/08
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
