SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
24" SINGLE SPACE SAVER OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
33C 4526108
Oven Door Handle Kit, 20W, Sunre
Note: Kit includes items 31B, 32B, 33B
1 15AUG/08
34 1082802 Hinge Link Rt 1 C
35 4522772 Bell Crank Assembly 1
36 F299 Bolt 1/4-20x1/2" Bell Crank 1
37 4522818 Bell Crank Support Bracket 1
38 1005800 Oven Door Spring - Garland 1 C
39 9004701 Oven Door Spring Hook 1
40 4523654 Spring Support Bracket (20W Door) 1
41 4523039 Kick Panel 20W 1
42
4525442 Knob Assembly - Sunre Oven SIT, deg. F 1 C
4525443 Knob Assembly - Sunre Oven SIT, deg. C 1 C
43 4523081 ES Shield Mount 1
44 4523006 SIT Oven Control 1 C
45 1095499 Straight Connector 7/16 2
46 4523079 ES Shield Rt 1
47 4523080 SIT Lt Shield 1
48 4523499 SIT Top Shield 1
49 4523145 Tube - Sit To Manifold 1
49A 4520720
7/16" Flexible Tubing Sit To Manifold
NOTE: Applicable Only for Models with 12"Griddles
Mounted on the L/H Side of the Range.
1
50 4522411 Rack Guide 26D 2
51 4522410 Oven Rack 20W x 26D 1
55 4522991 Corner Column Rt 24" 1
56 4522990 Corner Column Lt 24" 1
57 F298N
Bolt, #10-24 x 3/8" Shoulder Truss HD, Nickel Plated
(was F298)
2
58
4523199
24 Valve Panel
All Burners or 2” Standard Griddle on L/H or R/H
Note: Used from (serial#) 0911100101162.
(4523594 is obsolete, used up to 1-Dec/09)
1 2DEC/09
4523621
24” Valve Panel - 24" Griddle (Standard)
Note: Used from (serial#) 0911100101162.
(4523635 is obsolete, used up to 1-Dec/09)
1 2DEC/09
58A 4523746 2.5” Valve Panel Hole Cover (Storage Base Option)
59 4523252 24" Plate Rail, Sunre 1
60 4527427
Valve Panel End Cap - Left (was 4523251)
Note: Used from (serial#) 0911100100549 (model) X60-
6R24RR-0003.
1 17NOV/09
61 4527426
Valve Panel End Cap - Right (was 4523250)
Note: Used from (serial#) 0911100100549 (model) X60-
6R24RR-0003.
1 17NOV/09
62 4526110 Burner Box Filler (was 4523193) 2
63 4522561 Manifold Assembly - 24" (without Fittings) 1 C
64
2127502 Regulator - Natural Gas 4.5" WC 1 C
2127500 Regulator - Propane Gas 10" WC 1 C
65 4529768 90 deg Elbow Fitting,7/16CC to 3/8NPT (was G02352-1) 1
* NOT ILLUSTRATED
