SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
24" SINGLE SPACE SAVER OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
66 G022511 Pressure Test Spigot 1
67 2203400 1/8" NPT Pipe Plug 2
68 4523570 .187 (3/16) Dia Tubing - SIT Valve to Oven Pilot 1
68A 4527220 SIT Pilot Tube Connection 1
69 4530485 .437 (7/16) Dia Tubing - SIT Valve to Oven Orice Fitting 1
70 4523043 Air Shield Pilot 20W 1
71 4523042 Air Shield Solid 20W 1
72 4523052 Capillary Guard 20W Standard Oven 1
73 4523030 Bulb Guard Standard Oven 1
74 4523194 Rail Support Bracket 1
75 1082700 Harness Ring, Nickel Plated 2
76 4522400 Trunion Bracket 2
77 4523087 Grate Support Rail 1
78 4523186 24" Drip Angle 2
79 1005110 Flue Collar - Aluminized 1
89 4525041
Hearth Support, L/H 26D (removable)
Note: Used FROM (serial#) 0804100101527 (model)
X60-10RR.
1 1MAY/08
90 4525042
Hearth Support, R/H 26D (removable)
Note: Used FROM (serial#) 0804100101527 (model)
X60-10RR.
1
91 4523051 Fireplate, 20W Oven, Sunre
92 4522384 Oven Hearth 20W x 26D - Enamelled 1
95 F16
SIT to Manifold Mounting Bolts (#10-24 x 2-1/2", Round
Head, Slot Drive)
2
96 F312
SIT to Manifold Mounting Lock Nut (#10-24, K-Lock
Nut)
2
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
