Sunfire X24 - Hot Top

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 27
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
HOT TOP
ITEM PART # DESCRIPTION
HOT TOP
FROM UP TO
CRITICAL
12” 24” 36”
1 4525514 Hot Top / Griddle Burner Box 1 2 3
2 4525463
H-Burner W/Shutter Assembly (Partially Ported)
Note: Assembly includes a cast iron H-burner
(p/n 1014901) and an air shutter.
1 2 3
4 1028002 Air Shutter - Hot Top / Griddle 1 2 3
5 2200701 Pilot L/H #0.145.007 1 2 3 C
6 4525503 Pilot Bracket 1 2 3
11 4524158 Griddle / Hot Top Box Patch 1 2 3
15 1086597 Pilot Gum Valve 1 2 3
16 4522585 Knob - Sunre 1 2 3
20 4523483 Hot Top Valve Extension Support 1 2 3
21 4523148 Hot Top 12" Assembly 1 2 3
22 4523286 3/16" Tubing Hot Top Pilot To Gum Valve 1 2 3
23 4525515 Burner Side Deector 2 4 6
25
2200702 Pilot Orice #32 Natural Gas 1 2 3 C
2200703 Pilot Orice #23 Propane Gas 1 2 3 C
27 2200704 3/16" Compression Nut 1 2 3 C
28 2200705 3/16" Ferrule 1 2 3 C
29 4522401 Crumb Tray 1 2 3
30 4522403 Crumb Tray Trim 1 2 3
31 CK4523335 Crumb Tray Assembly - Sunre 1 2 3
32 F554 Rivet .125" Dia. SS 2 4 6
37A
1086580
Hi-Low Valve Assembly, Natural Gas #47 w/
Extension and Orice
1 2 3 1DEC/09 C
1086595
Hi-Low Valve Assembly, Propane Gas #1.3mm
w/ Extension and Orice
1 2 3 1DEC/09 C
37B 26878XX
Open Burner Valve, no Hood
Note: Used UP TO (date) 2-May/12 (model)
G36-6R-0005 / U36-6C-0014 (serial#)
1204100101467 / 1204100101482
1 2 3 2DEC/09 2MAY/12 C
37C 4530671
Open Burner Valve, no Hood
Note: Used FROM (date) 2-May/12 (model)
G36-6R-0005 / U36-6C-0014 (serial#)
1204100101467 / 1204100101482
1 2 3 2MAY/12 C
38 2706802 Valve Extension, 3.25” 1 2 3 C
39
M847 Hot Top/Griddle Orice Natural Gas #47 1 2 3 C
M81.3MM Hot Top/Griddle Orice Propane Gas #1.3mm 1 2 3 C
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
