Sunfire X24 - Page 34

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 34
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
RAISED GRIDDLE BROILER TOP
ITEM PART # DESCRIPTION QUANTITY
CRITICAL
38 4523815 Broiler Box Shield 1
39 4523823 RGB Pilot Bracket 3
40
1473700 Broiler Pilot Assembly - Natural Gas 3 C
1473701 Broiler Pilot Assembly - Propane Gas 3 C
41 4524667 RGB Pilot Tubing 3
42 1086597 3/16" Pilot Gum Valve 3
43
4524682 Valve Panel End Cap Right RGB (Used UP TO 16-Nov-2009)
4527428
Valve Panel End Cap Right RGB, X Series
Note: Used FROM (date) 17-Nov-09 (serial#) 0911100100549
(model) X60-6R24RR-0003
1
44
4523251 Valve Panel End Cap Left, Sunre (Used UP TO 16-Nov-2009) 1
4527427
Valve Panel End Cap Left, Sunre
Note: Used FROM (date) 17-Nov-09 (serial#) 0911100100549
(model) X60-6R24RR-0003
1
45 4526110 Burner Box Filler (was 4523193) 2
46
4524680 36" Valve Panel - RGB Right (Used UP TO 01-Dec-2009) 1
4523736
36" Valve Panel - RGB Right
Note: Used FROM (date) 02-Dec-09 (serial#) 0911100101162
1
49 4523253 36" Plate Rail, Sunre 1
50A 4523832 RGB Tray Trim S/S 1
50B 4523828 RGB Grease Tray 1
50C F554 Rivet .125" Dia. SS 1
50D CK4523828 RGB Grease Tray Assembly 1
52 4522565 60" Manifold Assembly RGB Right (without ttings) 1 C
53 1028002 RGB Burner Air Shutter 3
54 1090500 RGB Burner 3
56 4523822 RGB Burner Rest 1
57 1090600 RGB Wire Rack 1
58 4524648 RGB Wire Rack Drip Shield 1
59 4523746 2.5" Dia Nickel Plated Steel Hole Plug - Storage Base Left/Right MAX 2
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
