Sunfire X24 - High Shelf (HS) Components; Low Profile Back Guard (LPBG) Components

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 37
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
HIGH SHELF & LOW PROFILE BACK GUARD COMPONENTS
ITEM PART # DESCRIPTION QUANTITY
High Shelf (HS) Components
1 4523112 High Shelf Upright (Vertical Side Channel) 2
2
4523267 24" HS Back Panel 1
4524105 24" HS Back Panel - S/S 1
4523111 36" HS Back Panel 1
4523312 36" HS Back Panel - S/S 1
4523290 48" HS Back Panel 1
4524106 48" HS Back Panel - S/S 1
4523268 60" HS Back Panel 1
4524107 60" HS Back Panel - S/S 1
3A
4523289 24" HS Front Panel 1
4523110 36" HS Front Panel 1
4523291 48" HS Front Panel 1
4523264 60" HS Front Panel 1
3B 4523833 60" HS Front Panel - for Raised Griddle Broiler Model Only 1
4
4523293 24" Shelf 1
4523113 36" Shelf 1
4523294 48" Shelf 1
4523270 60" Shelf 1
9" Low Prole Back Guard (LPBG) Components
NOTE: ALL 6" Low Prole Back Guard Components are No Longer Available (NLA).
Replacing any 6" Low Prole Components will require
a complete conversion to the 9" Low Prole Back Guard Assembly.
5
4525520 9" LPBG Upright (Vertical Side Channel) 2
4524097
9" LPBG Upright (Vertical Side Channel) for Raised Griddle Broiler
Model Only
2
6
4525521 24" LPBG Back Panel 1
4525522 24" LPBG Back Panel - S/S 1
4525523 36" LPBG Back Panel 1
4525524 36" LPBG Back Panel - S/S 1
4525525 48" LPBG Back Panel 1
4525526 48" LPBG Back Panel - S/S 1
4525527 60" LPBG Back Panel 1
4525528 60" LPBG Back Panel - S/S 1
4523887 60" LPBG Back Panel - for Raised Griddle Broiler Model Only 1
4523895 60" LPBG Back Panel - S/S - for Raised Griddle Broiler Model Only 1
7A
4525516 24" LPBG Front Panel 1
4525517 36" LPBG Front Panel 1
4525518 48" LPBG Front Panel 1
4525519 60" LPBG Front Panel 1
7B 4523886 60" LPBG Front Panel - for Raised Griddle Broiler Model Only 1
