Setting range: 00:00:00-23:59:00
Setting range: 00:00:00-23:59:00
Setting range: 00:00:00-23:59:00
Timed start discharging
enable
After the time-slot discharge function is enabled, the power
supply mode will change to AC 1ST and the system will switch
to battery inverter power supply only during the set discharge
period or when the mains power is off.
1st slot start
discharging
Setting range: 00:00:00-23:59:00
Setting range: 00:00:00-23:59:00
2nd slot start
discharging
Setting range: 00:00:00-23:59:00
Setting range: 00:00:00-23:59:00
3rd slot start
discharging
Setting range: 00:00:00-23:59:00
Setting range: 00:00:00-23:59:00
User-defined, user can set all battery parameter.
Sealed lead-acid battery.
Flooded lead-acid battery.
LFP li-ion battery, L14\L15\L16 corresponds battery cells
number in series.
Current setting range:0~100A.
Setting range:48V~58.4V, increment of each click is 0.4V,
parameter can be set only when battery type is USER and
L14/15/16,N13/14
When the battery voltage falls below this voltage point and
parameter ‘Stop dchg. delay time’ value is reached, the
inverter output will be switched off. Setting range: 40V~48V,
increment of each click is 0.4V, parameter can be set only
when battery type is USER and L14/15/16,N13/14
Indicates the duration when battery voltage reached parameter
“stop discharge voltage” value in over-voltage procession.
Setting range: 5s~50s, increment of each click is 5s, parameter
can be set only when battery type is USER and
LFP14/15/16,NCM13/14
Battery Under Volt
（alarm） Point
When the battery voltage is lower than this judgment point,
the device will under-voltage alarm, the output will not shut
down, setting range 40V~52V, step 0.4V
Battery recover discharge from under voltage protection when
voltage above this value. Setting range: 44V~54V.
