6.2、RS485/CAN communication port
1.RS485/CAN communication port for RS485 and CAN
communication with lithium battery BMS;
6.3、 DIP switch
When RS485 port PIN1 and PIN2 are used for BMS 485 communication, put down DIP 1,2,
When RS485 port PIN7 and PIN8 are used for BMS 485 communication, up DIP 1,2
When using a single machine, put down DIP 3,4
When the inverter are in parallel, put down DIP 3,4, of any two inverters
6.4、WIFI port
The WIFI port is used to connect to the Wi-Fi/GPRS data acquisition module,
which allows the user to view the operating status and
parameters of the inverter via the mobile
