7.7.8 Power Regulation Parameters
Click “Power Monitoring→Power Regulation Parameters”, and set power regulation pa-
rameters on the corresponding interface.
Two methods are available for power regulation parameter setting: Single Setting and Batch
Settings. Please refer to "7.7.3 Initial Parameter" for details of setting methods.
7.7.9 General Parameters
Step 1 Click “Device monitoring→General Parameters” to enter the corresponding interface and
set general parameters.
Step 2 Select Read-back, set Register Address, Register Number, and Address Type, and click
the button Read-back, to read the current value of the device.
Step 3 Select Settings, set Register Address, Data Type, and set Value, and click the button
Save. Parameters can be set for a single device.
For parameters that need to be set, refer to corresponding communication proto-
col of the inverter.
Step 4 (Optional) Select Settings, set the Register Address, Data Type and set Value, and Click
Configure Synchronization. In the pop-up list of devices, check the devices that need to
be set, and click Save. You can set the parameters for multiple devices.
- - End
7.7.10 Device Instruction
Click “Device Monitoring→Device Instruction” to enter the corresponding interface.
On this interface, users can boot/shutdown the device or reset all settings.
Device instruction can be set in two manners: single setting and batch setting. Take the boot
operation as an example for explanation.
7.7.10.1 Single setting
Step 1 Select a device, click Boot, and a dialog box pops up.
Step 2 Click Yes to start a single device.
- - End
7.7.10.2 Batch setting
Step 1 Select a device, click Boot, and a dialog box pops up.
Step 2 Click Configure Synchronization.
Step 3 Select the desired devices in the pop-up device list, and click Save to achieve batch setting.
Step 4 Click Confirm on the pop-up dialog box.
- - End
User Manual 7 WEB Interface
