Sungrow Logger1000B User Manual

86
8.3.2.4 Analog Input
When using the analog signal at the AI port of the Logger1000 as the dispatching input, set
the Reactive Control Mode to Analog input.
Step 1 Click “Power control→Reactive power” to enter the reactive power interface.
Step 2 Set the reactive control mode to Analog input.
Step 3 Set AI control parameters. For specific parameter description, refer to the following table.
table 8-9 Parameter description
Parameter
Description
Control method
Open-loop control: Reactive instruction controlled by AI is sent
to power output port of the inverter, thereby achieving active
power control.
Closed-loop control: Reactive instruction controlled by AI is
used as target value and reactive power and power factor of the
meter need to be collected and used as input parameters, and re-
active power compensation ratio is calculated and sent to power
output port of the inverter. Generally, this strategy is used for im-
proving the power factor of the property boundary point.
Select energy meter /
transformer*
Select Smart Energy Meter involved in power regulation
Control cycle
Time interval of delivering dispatching instructions
Parameter range: 5~60s
AI port
AI1~AI4 available
Instruction Type
PF: set the power factor as the target value
%: set reactive power percentage
Min. / Max.
When Instruction Typeis set to %, the parameter ranges from
-100.0% to 100.0%.
When Instruction Type is set to PF, the parameter ranges from
-1 to -0.8 or 0.8 to 1.
Step
The minimum difference value between two consecutive power
dispatching instructions
Hysteresis range**
When the parameter Instruction Type is set to PF, dispatching
output maintains to be PF±1
Note: *Only when the control method is set to Closed-loop control, the parameter Select
energy meter / transformer is settable.
** Only when the control method is set to Open-loop control and the Instruction Type to
PF or when the control method is set to Closed-loop control, a Smart Energy Meter is se-
lected, and the Instruction Type is set to PF, the parameter Hysteresis range is settable.
8 Grid Dispatching Function User Manual
