57
Step 4 Open the sheets such as inverter, Smart Energy Meter, Meteo Station, and Logger1000, to
set corresponding measuring point data.
table 7-7 Parameters of each equipment tab
Data
Type
DataID State Invert
Coeffi-
cient
Unit
Data
Name
YC 1 Y N 1000 W P
YC 2 Y N 1000 Var Q
YX 3 Y Y 1 NA
On-grid
YX 4 Y N 1 NA
Off-grid
YM 5 Y N 1 kWh
E-Daily
YK 6 Y N 1 NA
Power On
/ Off
YT 7 Y N 1 kW P-Set
YT 8 Y N 1 Var Q-Set
table 7-8 Description of parameter
Parameter Value
Description
Data Type
-
Data type
Data ID
-
Data type
State*
Y
Data is uploaded to the background via the
IEC104 communication protocol
N
Data is not uploaded to the background
Invert*
Y
Negate, 0 is 1, and 1 is 0, available for telesig-
nalling only
N
No negate, 0 is 0 and 1 is 1
Coefficient*
-
Coefficient, available for telemetry, remote
pulse, and remote regulating only
Uint
-
Unit, available for telemetry, remote pulse, and
remote regulating only
NA indicates no unit
Data Name
-
Data name in multiple languages
Note: * indicates that the parameters should be set according to onsite conditions.
User Manual 7 WEB Interface
