72
No.
Description
E
Language selection button. Click it to switch languages in multiple languages.
F Present date and time.
Enter the following submenus from the default menu.
10.2.3 Backlight and Screensaver
If no operation has been performed on the screen for more than 5 minutes, the backlight will
go off. Tap the screen to activate the backlight so that the latest interface reappears.
10.3 Overview of Submenu and Icon
There are three buttons on the lower left side of the touch panel: for the user to operate
“Start/Stop”
, “Home”, , “Function” . The user can perform related oper-
ations via these buttons. The logical structures of these menus are shown below:
Main Menu First sub-menu Second sub-menu Third sub-menu
Start/Stop
Start
- -
Stop
- -
Home
- - -
Function
Set-parameter
Control Mode
SG1100UD
SG2200UD
SG3300UD
SG4400UD
The control mode is subject to the actual product.
10.4 Setting Language
The language setting shortcut (shown by A) is at the lower right corner of the Home menu.
Select either language by tapping the language button.
By tapping the button, the language will switch among English, Chinese and the like.
The language displayed on the button is the present display language.
10 LCD Menu Operation (Optional) System Manual
