Sungrow SG20KTL-M Quick Guide

TD_202101_Logger1000_Quick Guide for 3-Phase PV Inverters (5-20kW)_V1.2 Page 5 of 16
© Sungrow Power Supply Co., Ltd. All rights reserved.
As we continuously improving our services, changes to this document may occur without notice.
Note: Make sure the splitter splits 8-pin cable into two 8-pin outputs. Some of the
splitters only divide 8-pin cables into two groups of 4-pin outputs which will not work.
Note: Never connect the meter to the same RS485 terminals as the inverters.
Logger 1000
RS485 A
RS485 B
RS485 A
RS485 B
3-Phase meter
Inverter 1
Inverter 2
