Sungrow SH3K6 Quick User Manual

2 Electrical Connection Quick User Manual
12
(Optional) Only for parallel mode.
4
5
2.5 Communication Connection
2.5.1 Ethernet Connection
Connect the inverter to the PC through the Ethernet port to set up the Ethernet
communication. The Ethernet connection with a router is shown in the following
figure.
Router/Switch
Inverter
Internet
SolarInfo Moni APP
Local access
Remote
SolarInfo Bank server
SolarInfo Bank
Webserver Explorer
Use a TIA/EIA 568B standard network cable with a diameter of 3 mm–5.3 mm.
Remove the cable jacket by 8 mm–15 mm, and use the Ethernet crimper to
crimp the cable.

Sungrow SH3K6 Specifications

General

Model	SH3K6
Max. Input Voltage	600 V
Number of MPPTs	2
Total Harmonic Distortion	< 3%
DC Switch	Yes
Protection Class	IP65
Cooling Method	Natural convection
Protection Level	IP65
Nominal AC Voltage	230 V
AC Voltage Range	180-280 V
Output Voltage	230 V
Nominal Grid Frequency	50 Hz
Frequency	50 Hz
Operating Temperature Range	-25°C to +60°C
Operating Temperature	-25°C to +60°C
Humidity	0% - 100%
