sunjoe SPX3160 - Unpacking and Assembly; Unpacking Contents; Spray Gun Assembly; Installing Wheels

6
Unpacking
Carton Contents
• Electric pressure washer
• Trigger gun
• Caster wheel (2)
• Wheel (2)
• Spray wand
• Spray wand assembly
• Foam cannon
• High-pressure hose
• Garden hose adapter (female coupler)
• Needle clean-out tool
• Manual with registration card
1. Carefully remove the pressure washer and check to see
that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new electric
pressure washer. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils,
or small parts. These items can be swallowed and pose a
suocation risk!
mWARNING! Do not connect to power supply until
assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
Assembly
Spray Gun Assembly
1. Fit the two pieces of the spray wand assembly together
and rotate until they are completely locked (Fig. 1).
2. Fit the spray wand assembly into the gun and turn the
rotatable end-piece of the wand until the two parts are
completely locked (Fig. 2).
Installing Wheels
1. Install the caster wheels onto the front of the pressure
washer by inserting them into the two holes on the bottom
of the housing (Fig. 3). Press wheels down rmly to
secure.
Fig. 1
RELEASE
Spray wand assembly
Trigger gun
Fig. 2
Fig. 3
Caster wheels
