SUNPOWERCORPORATION
SafetyandInstallationInstructions‐Document001‐14158RevAI


©2021SunPowerCorporation.Allrightsreserved.Specificationsincludedinthismanualaresubjecttochangewithoutnotice. Page|11



Platform
Modulemountingandgroundholedetail
FORA‐SERIESMODULES
Commercial
Modules
Gen4.2FRAMEMODULE(72‐CELL) Gen5.1FRAMEMODULE(72‐CELL)
1935 76.2
1423 56.0
1200 47.2
539 21.2
400 15.7
973 38.3 980 38.6
1058 41.7
1999
78.7
1016
40.0
20x Ø6.8 [.27]
MOUNTING HOLES
4x Ø4.22 (GND)
5x15 [0.2x0.6]
SLOTS


SIDEFRAMEPROFILE ENDFRAMEPROFILE SIDEFRAMEPROFILE ENDFRAMEPROFILE
40 1.57
32 1.26

40 1.57
24 .94

30 1.2
40 [1.57]

22 .9
40 [1.57]


FORA‐SERIESMODULES FORM‐SERIESMODULES
Residential
Modules
Gen5.2FRAMEMODULE(66‐CELL) Gen5.2FRAMEMODULE(66‐CELL)
[40 mm]
1.57 in
[1835 mm]
72.2 in
[1016 mm]
40.0 in


1872 [73.7]
1032 40.6
4X Ø 4.2mm [0.17]
Ground Holes
40[1.57]
4X Ø 6.8mm [0.27]
Mounng Holes
1100 [43.3]

SIDEFRAMEPROFILE ENDFRAMEPROFILE SIDEFRAMEPROFILE ENDFRAMEPROFILE
32 1.26
40 [1.57]

24 .94
40 [1.57]

32 1.26
40 [1.57]

24 .94
40 [1.57]

*See Product Rating Label for Maximum System Voltage.
