SunPower E Series - Page 10


SUNPOWERCORPORATION
SafetyandInstallationInstructions‐Document001‐14158RevAI


©2021SunPowerCorporation.Allrightsreserved.Specificationsincludedinthismanualaresubjecttochangewithoutnotice. Page|10

Platform
Modulemountingandgroundholedetail
FORP‐SERIESCOMMERCIALGEN4.0FRAMEMODULE
Commercial
Modules
4X
398 mm
998 mm
2067 mm
46 mm
300 mm
400 mm
539 mm
1058 mm
1200 mm
2043 mm
1423 mm
1606 mm
4X Ø
6.6mm
Mounti
ng Clip Holes
4X Ø
4.8mm
Drain Hol
es
4X Ø
4.2mm
Ground Holes
4X
5.0mm (W) X 15.0mm (L)
SL
O
T
20X
Ø 6.8mm
Mounti
ng Holes
4X Ø 7.0mm
Stacking Pins
954 mm
961 mm

SIDEFRAMEPROFILE ENDFRAMEPROFILE

WithStackingsPins

FORP‐SERIESGEN4.1FRAMEMODULE
Commercial
Modules
998 mm [39.3]
46 mm
[1.8in]
MODEL: SPR-P19-410-COM
Rated Power (Pmax)
1
(+5/
0
%)
410
W
Voltage (Vmp) 43.9
V
Current (Imp) 9.35
A
Open-Circuit Voltage (Voc) 53.1
V
Short-Circuit Current (Isc) 9.94
A
Maximum Series Fuse 15
A
1
Standard Test Conditions: 1000 W/m
2
, AM 1.5, 25° C
Suitable for ungrounded, positive, or negative grounded DC systems
Field Wiring: Cu wiring only, min. 12 AWG/4 mm
2
, insulated for 90° C min.
WARNING
SEVERE ELECTRICAL HAZARD
• Solar module has full voltage even in very low light.
• Installation should only be done by a qualified technician.
527040
www.sunpower.com
Patented as shown at www.sunpower.com/patents
Safety Class II
Fire Rating: Class C
Max. System Voltage:1500 V DC
954 mm [37.6]
961 mm [37.8]
2067 mm [81.4 in]
300 mm
400 mm [15.7 in]
539 mm [21.2 in]
1058 mm [41.7 in]
1200 mm [47.2 in]
1423 mm [56 in]
1606 mm [63.2 in]
4X Ø 4.2mm [0.26in]
Ground Holes
20X Ø 6.8mm[0.27in]
Mounting Holes
4X 5.0mm (W) x 15.0mm (L)
SLOT
[
11.8in]
[21.2 in]

998 mm
[39.3 in]
2067 mm [81.4in]
46 mm
[1.8 in]
300 mm
400 mm [
15.7 in]
539 mm [21.2 in]
1058 mm [41.7 in]
1200 mm [47.2 in]
1423 mm [56 in]
1606 mm [63.2 in]
[
11.8in]
998 mm
4X Ø 4.2mm[0.26in]
Ground
4X 5.0mm (W) x 15.0mm (L)
SLOT
20X Ø 6.8mm[0.27in]
Mounting Holes

SIDEFRAMEPROFILE ENDFRAMEPROFILE
46mm
32mm

46mm
24 mm

Method1:
FrameHole
Locations
*See Product Rating Label for Maximum System Voltage.
