SUNPOWERCORPORATION
SafetyandInstallationInstructions‐Document001‐14158RevAI


©2021SunPowerCorporation.Allrightsreserved.Specificationsincludedinthismanualaresubjecttochangewithoutnotice. Page|9


Platform Modulemountingandgroundholedetail
FORCOMMERCIAL(SILVERFRAME)MODULESONLY,INCLUDESSTACKINGPINS
Commercial
Modules

96‐CELLCOMMERCIALMODULE 128‐CELLCOMMERCIALMODULE
1559 mm [61.4in]
1535 mm [60.4in]
1200 mm [47.2in]
1046 mm [41.2in]
1002 mm [39.4in]
(Back View)
(Front View)
915 mm [36.0in]
46 mm [1.8in]
3.2 mm
[0.13in]
398 mm
[15.7in]
4X Ø6.10 mm [0.24in]
Stacking Pins
6X Ø4.2 mm [0.17in]
Ground Holes
12X Ø6.6 mm [0.26in]
Mounting Holes
4X Ø4.8 mm [0.19in]
Drain Holes

Stacking Pins
4X Ø6.10 mm [.24in]
300 mm
[11.8in]
20X Ø6.8 mm
Mounting Holes
4X Ø4.2 mm [.17in]
Ground Holes
4X Ø4.8 mm [.19in]
Drain Holes
398 mm
[15.7in]
3.2 mm [.13in]
46 mm [1.8in]
(Front View)
(Back View)
1046 mm [41.2in]
1002 mm [39.4in]
2067 mm [81.4in]
1200 mm [47.2in] 1423 mm [60.4in]
539 mm [21.2in]
400 mm [15.7in]
1058 mm [41.7in]
SLOT 5.0(W) X 15.0 (L)

SIDEFRAMEPROFILE ENDFRAMEPROFILE

WithStackingsPins

FORCOMMERCIAL(SILVERFRAME)MODULES
ONLY,INCLUDESSTACKINGPINS
FORGEN6FRAMEMODULEONLY
Commercial
Modules

1098 43.2
1002 39.4
1535 60.4 1200 47.2
915 36.0
12x Ø 6.80
(MOUNTING)
1559 61.4
1046
41.2
4x Ø 4.2 [.17]
(GROUND)


SIDEFRAMEPROFILE ENDFRAMEPROFILE SIDEFRAMEPROFILE ENDFRAMEPROFILE

WithStackingsPins



Method1:
FrameHole
Locations
Method1:
FrameHole
Locations
*See Product Rating Label for Maximum System Voltage.
