SIM7090G EVB Kit User Guide V1.00
www.simcom.com
- 9 -
3. Accessory Interface
3.1 Power Interface
Both USB interface (A) and UART Port interface (B) provide power supply for EVB.
Pin Signal I/O Description
A and B USB power Input I 5V/0.5A DC Source Input
3.2 Audio Interface
Figure 4: Audio Interface
