151
Function No. : 076 Function Name : Setting-up reference point for zooming
On sewing mode, the user can zoom design based on machine origin, second origin, sewing starting
point and user-defined reference point.
Zooming based on the machine origin (Factory Default)
[Contents] Scaling up/down based on the current machine origin.
076. Scale Refer
1) MACHINE_ORG
Setting
Value
Zooming based on the second origin set by user.
[Contents] Scaling up/down based on the second origin set by user at any location.
2) SECOND_ORG
Zooming based on the reference on the sewing starting point
[Contents] Zooming based on the first stitch of any pattern design.
3) SEWING_STRT
Zooming based on th reference point defined by user at any location.
[Contents] Zooming based on the reference point defined by user at program code No.058
of <Function Code>.
4) REFER_PNT
Function No. : 077 Function Name : Palette signal check
If there would be sensor attached on the upper feed plate, define whether to user the signal check.
No signal checking (Factory Default)
[Contents]
077. Palette Chk
1) DISABLE
Setting
Value
Signal checking
[Contents]
2) ENABLE
To Next Page
