3-14) Setting-Up Reference Point for Zooming
On the sewing mode, the user can zoom design based on machine origin, second origin, sewing starting
point or user-defined reference point. However, the second origin and user-defined reference point must be
set in the pattern design before zooming based on those reference points.
E. When deleting stitches or pattern, the user can
confirm the automatic insertion of thread
trimmer by either making new design or
retrieving the existing design saved in a USB flash
drive. Please refer to “2-3) Delete Number of
Stitches”and “2-4) Partially Delete Pattern Data”.
ORIGIN NONE
X:00000A N:00000
Y:00000A
Function Code?
<< Main Menu >>
1. Parameter Set
2. Program
3. Bobbin Wind
A. Press MODE.
B. Use direction key to select “1. Parameter
Set”menu.
<Parameter Set>
PARA No :076
C. Press ENTER to open a screen shown on
the right. Input [0][7][6] and press ENTER
to move onto the 076. Scale Refer item.
076. Scale Refer
1) MACHINE_ORG
2) SECOND_ORG
3) SEWING_STR
4) REFER_PNT
D. The following four items of zooming reference
point are displayed.
By default, it is set on MACHINE_ORG. Use
direction key to select the item desired, and
then press ENTER to set.
Descriptions of each item are as follows:
MACHINE_ORG : Zooming based on the machine origin.
SECOND_ORG : Zooming based on the second origin.
SEWING_STR : Zooming based on the sewing starting point.
REFER_PNT : Zooming based on the point defined by user at program code No. 076 of Function
Code.
