3-17) Sewing Limit Function
This function for setting sewing limit is designed to expand the mechanical sewing limit of the machine.
First mechanically expand the X-Y feeding area of the machine, and set the sewing limit in the parameter
in accordance with the expanded area.
※In case of C-Series, the area can be expanded up to 25000×25000mm.
<< Main Menu >>
1. Parameter Set
2. Program
3. Bobbin Wind
A. Press MODE and select Parameter Set in Main
Menu.
Refer to the following for set-up.
< Parameter Set >
078. Sewing Limit
079. XPLUS Limit
080. XMINUS Limit
078.Sewing Limit
1) DISABLE <
2) ENABLE
B. Use the direction change cursor in the
Parameter Set and select 078. Sewing Limit.
C. Sewing Limit is defaulted at 1) DISABLE.
<< Main Menu >>
7. OtherPtrnCall <
E. When conversion is finished, the screen returns
to the original status.
<< Main Menu >>
5. Pattern List <
6. EMB Call
7. OtherPtrnCall
F. Press No. 5 “Pattern List" from the main
menu, and check whether the converted file
from the USB flash drive is properly saved.
Memory(0)/USB(1)
To Exit(ESC)...
G. Press No. 1.
<< Pattern List >>
001 <
H. The list of design patterns saved is displayed.
Enter Number to
be stored
NO:001
D. Enter a new name for the file, which will be
converted and saved, and press “Enter."
