2) Menu Screen (LCD)
Displays the set-ups and the main & sub menus selected.
① Set-up
There are 10 types of set-up information. Four will be listed at a time. Press UP or DOWN on the right side of
the LCD screen to move to another screen.
NO: memory number of the selected design
STITCH: number of total stitches in the selected design
COLOR: number of color changes (needle bars) in the design
JUMP: number of jump stitches in the design
X[mm]: the X dimension (left to right) of the selected design
Y[mm]: the Y dimension (top to bottom) of the selected design
ANGLE: the selected orientation of the design by degrees
MIRROR: if the reverse function is selected
X_SCALE: if the design has been scaled up or down in the X direction
Y_SCALE: if the design has been scaled up or down in the Y direction
The above data are accurate based on instant calculation.
② Sub Menus
Main menus are selected by keys on the control panel. Sub menus will appear on the screen at your selection
of a main menu. All sub menus cannot be indicated on a single screen. Use UP/DOWN buttons to move to
another screen.
Ex) selection of basic set-up
NO : 8
STITCH : 16850
COLOR : 6
JUMP : 118
X [mm] : 83.4
Y [mm] : 101.6
ANGLE : 45
MIRROR : OFF
X_SCALE : 100
Y_SCALE : 100
1] X_SCALE : 100%
2] Y_SCALE : 100%
3] ANGLE : 0
4] MIRROR : NO MIRROR
