Maintenance notes
The pond motor pump is a maintenance-free and a practice-proven quality product that was subjected
to rigorous final inspections. For a long working life and continuous operation we recommend regular
checking and proper care.
Winter Storage
1. Take the pump out of the water and disconnect it from the power supply.
2. Clean the pump, as described in the instructions.
3. Check the pump for damage, such as cracks in the housing.
4. Please store the pump under frost-free conditions, if possible in a container filled with water.
Construction of the Pump
№ Name № Name
1 Nut 10 Bearing housing
2 Large o-ring 11 Motor
3 Stepped hose nozzle 12 Rubber stopper
4 Adaptor 13 Fastening clip
5 Small o-ring 14 Upper filter cage
6 Pump housing 15 Motor bracket
7 Impeller 16 Inlet guard
8 Impeller o-ring 17 Lower filter cage
9 Impeller bearing 18 Upper filter cage ring
© by WilTec Wildanger Technik GmbH Item 51000–51011 Page 5
http://www.WilTec.de
http://www.aoyue.eu 12 2020-1
http://www.teichtip.de
