SunSynk SUN-BATT-5.12 - Switch ON;OFF; LED Indicator Definition

SUN-BATT-5.12 | User Manual6
Status
RUN ALM Battery Level Indicator
Discriptions
L8 L7 L6 L5 L4 L3 L2 L1
Shut down OFF OFF OFF OFF OFF OFF OFF OFF All OFF
Standby Flash 1 OFF According to the battery level Indicates Standby
Charging
Normal Light OFF According to the battery level
The highest capacity
indicator LED ashes
(ash 2),others lighting
Full
Charged
Light OFF Light Light Light Light Light Light
Turn to standby status
when charger o
Protection OFF Light OFF OFF OFF OFF OFF OFF Stop charging
Dis-
charge
Normal Flash 3 OFF According to the battery level
UVP OFF OFF OFF OFF OFF OFF OFF OFF Stop charging
Protection OFF Light OFF OFF OFF OFF OFF OFF Stop discharge
Fault OFF Light OFF OFF OFF OFF OFF OFF
Stop charging and
Discharge
2.2.1. Switch ON/OFF
Switch ON
For single SUN-BATT-5.12, switch ON rocker switch, then long press (more than 3 seconds) ON/OFF button on
front panel, LED will ash, then battery will operate normally. L1 to L6 shows battery SoC, L7/L8 shows battery
status.
For multiple SUN-BATT-5.12 in parallel, switch ON rocker switch on all batteries, long press (more than 3 sec-
onds) ON/OFF button of MASTER battery, LED will ash, battery system will automatically encode and assign ID
to each slave battery, then battery system will operate normally.
Switch OFF
Press start button of Master PACK more than 3s and then release the button, the master pack will shut down
after all slave packs shut down(Sleep mode) .
For single SUN-BATT-5.12, switch OFF rocker switch.
For multiple SUN-BATT-5.12 in parallel, switch OFF rocker switch on MASTER battery rst. Then switch OFF
rocker switch on all slave batteries
2.2.2. LED Indicator Denition
Note:
 ash 1 - 0.25s light / 3.75s o
 ash 2 - 0.5s light / 0.5s o
 ash 3 - 0.5s light / 1.5s o
