89
【Important】
Improper engine shut-down will damage turbocharger.
Set starting key to OFF position, stop the engine and
remove the key from starting lock.
Set pilot safety lock lever to LOCK position.
Open inspection door (right back door) for main pump,
check fluid level to ensure that hydraulic oil will be
between fluid level scales. Otherwise Refill if necessary.
Adding Oil
Note
There is pressure in hydraulic oil tank. Release pressure
before opening oil fill cap.
Release pressure, then remove oil fill cap on top of
hydraulic oil tank to fill oil.
Add oil and recheck fluid level.
Lock oil fill cap, make sure oil return cartridge and
suspension rod are positioned properly.
5.5.1.5 Drain Deposit In Fuel Tank
(1) To facilitate access, swing upper-structure 90°. Stop
the machine at level ground as shown in fig.
(2) Lower bucket to the ground.
(3) Run engine unloaded at low speed for 5 minutes.
(4) Shut off engine and take out key.(before start the
machine)
(5) Pull pilot control cut off rod to the the ―lock‖position
(6) Loosen drain valve underneath fuel oil tank to drain
water and deposit,then close drain valve.
5.5.1.6 Check Hose and Tubes for Leakage, Interference
Abrasion
Warning
Pressurized fluid can penetrate skin causing serious
injury.
To prevent being injured, use a card board to search
leakage. Be careful not to allow high-pressure fluid to
come into contact with body.
In case of accidents, contact experienced doctor for
medical attention.
