SUPAIR XP2 - Speed-Bag Adjustment

18
Speed-Bag adjustment.
4
8
6
7
9
5
8
9
B
B
D
D
E
E
Sliding system adjustment
Speed-bag lateral adjustment
Speed-bad tension adjustment
1 : During a hang-test, relax all the straps and seat inside the harness, without closing
the Sped-bag.
B
D
E
2 : Adjust the leg length via the sliding system length adjustment ( B ).
3 : Adjust the lateral straps ( D )
4 : By tensioning the top ( D ) more than the bottom ( B ) the Speed-bag will point upward.
5 : By tensioning the bottom ( B ) more than the top ( D ) the Speed-bag will point
downward.
6 : Close the Speed-bag. Tighten if necessary the Speed-bag tension straps ( E ).
The Speed-bag adjustment ( E ) must not have excess tension. The leg
push must be taken over by the sliding system ( B ) and the side straps ( D ).
B
D
E
