Specifications
Number of Wheels 4
Front Wheel Size 200mm (8”)
Rear Wheel Size 200mm (8”)
Ground Clearance (tiller)
60mm (2.4”)
Length 1010mm (40”)
Width 570mm (22.5”)
Weight Without Seat
Front frame : 10.2kg (22.4 lbs)
Front Frame Without Front wheels
:8.5kg (18.7 lbs)
Rear Frame : 10kg (22 lbs)
Weight of Seat 7.7kg (17 lbs included seat frame & armrest)
Max Loading 125kg (275 lbs) on level ground
Turn Radius 910mm (36”)
Motor Output 2 - 150 Watt
Transmission Worm Drive Gearbox
Reverse Forward/Reverse Switch
Brakes Dynamic Braking and Electromagnetic Brake
Braking Distance /
time
1-1.5 meter (39-59”) / 0.6 - 0.7 second
Battery (SLA/Lithium)
SLA : 24V - 15 ah 9.2kg (20 lbs) Lithium:
24V 12ah or 15ah / 3.2 kg (7 lbs) or 3.7 kg (8.1 lbs)
Charger (SLA/Lithium)
24 volt 2 amp / 24V 2 amp
Max Speed SLA Battery
6.5 kph (4 mph)
2
nd
speed choice
4.2 kph (2.6 mph)
Slope Grade Ability
Max. Recommended - 9 Degrees
Travel Distance
Up to 13 km (8.1 miles) with standard SLA battery, /
up to 17 Km (10.5 miles) or 13 Km (8.1 miles) with
24V 15ah or 12ah lithium battery.
Arm Rests
Distance between armrests 45cm - 55cm (18 -22")
- 37 -
SupaScoota Warranty
Your SupaScoota is fully guaranteed against faults arising due to
defects in manufacture or materials as follows
Frame: 2 years.
The height adjustable tiller and all other components except those
listed below: 1 year.
Subject to availability of parts, any such defects will be rectified,
either by repair or by unit replacement.
Warranty does not cover
Any damage due to improper use or the replacement of parts
arising from normal wear and tear such as potentiometers, tyres,
arm rests and upholstery.
Claims due to a normal increase in operational noise level.
This warranty does not cover labour or service calls.
Batteries
Batteries are covered by a six month warranty from the original
manufacturer. Gradual deterioration due to being left in a
discharged state or being left in cold conditions for long periods is
not covered.
- 38 -
