ASSEMBLE THE SEAT
Assemble the seat frame in the manner illustrated.
FOLDABLE SEAT FRAME - OPTIONAL
To open the seat frame
Pull out the knob “Z” in the
direction of the arrow and lift the
seat tube “C” up as illustrated.
Push the support lever in the
direction of the arrow until it
clicks into position “E”.
Warning: Pin “E” must be locked
into the position before using.
- 11 –
To fold the seat frame
Pull out the knob “Z” in the direction of the arrow
and push D downward as arrow illustrated
then push seat tube “C” downward
to fold the seat frame.
The armrests on your SupaScoota are not designed to be load
bearing.
DO NOT PUT EXCESSIVE WEIGHT ON THE ARMRESTS
