SECTION 3: SETUP MENU USAGE
NOTE
In the LENS SHAD menu, IR models provide only the OFF option.
• COMM ADJ (communication adjustment): Use function to set up the communication
status between the camera and an external controller. NOTE: PC33C5G and
PC153C5G cameras do not support PTZ.
— CAM ID: Set the camera ID number. Range: 0 ~ 255
— BAUD RATE: Select either 2400 / 4800 / 9600 / 19200 / 38400 / 57600 bps.
— PROTOCOL: Select either PELCO - D, PELCO - F, or NEX TCHIP.
— DISPLAY ID: Display camera title on the screen.
— ID POS: Use the joystick to set the position where the ID is displayed.
• LANGUAGE: Use to select the preferred menu language.
• VERSION: 21 01 10
RESET
• FACTORY: Reset the camera setting to the factory defaults.
• RETURN: Select this return to the SETUP menu.
EXIT
Press SET in the EXIT menu to save the current setting and exit the SETUP menu.
