Super Circuits PC33C5G - SECTION 5 Specifications

20
www.supercircuits.com
SECTION 5: SPECIFICATIONS
SECTION5 Specications
Model PC33C5G PC153C5G
Image Sensor 1/3” Sony CCD
Total Pixels 811(H) x 504(V) 537(H) x 505(V)
Eective Pixels 768(H) x 494(V) 510(H) x 492(V)
Resolution Color: 600 TV Line B/W: 700 TV Line Color: 450 TV Line B/W: 500 TV Line
S/N (Y Signal) 52dB (AGC OFF, Weight ON)
Min Illumination 0.1 LUX 0.05 LUX
Scanning System 2:1 Interlace
Synchronization Internal
DWDR OSD Control
Black Light BLC / HLC / OFF (selectable)
Electronic Shutter Speed 1/60 sec ~ 1/100,000 sec
White Balance OSD Control
Gain Control OSD Control
DNR OSD Control
D & N Selection OSD Control
Motion Detection OSD Control
Privacy OSD Control
Mirror (H-REV) OSD Control
Auto IRIS Lens Control OSD Control
Blemish Compensation OSD Control (DPC)
Video Output 1.0 Vp-p, 75 ohm LOAD
Audio High sensitivity microphone
Lens Mount C / CS
Power Supply 12 VDC / 24 VAC
Power Consumption 350mA (max) @ DC12V
