5
BATTERY
Caution: Incorrect battery wire connection may
cause a short-circuit, it may lead battery destroy,
fir or physical danger.
POWER SWITCH CONNECTION
Batter
Caution: Incorrect power switch cable connection may cause a short-circuit, it may lead battery destroy, fir
or physical danger.
RECHARGE
BASE
+
BATTERY
BATTERY
-
+
-
POWER SUPPLY
Red
Red
Red
Black
Black
Battery “-”（Black）
Battery “+”（Red）
Controller “-”（Black）
Controller “+”（Red）
Contol Switch Controller Motor Connection
Y
G
B
Y
G
B
