Chapter 1: Introduction
Note: The table above is continued on the next page.
Motherboard Features
Peripheral Devices
• Two (2) USB 2.0 ports on the rear I/O panel (USB 0/1)
• Two (2) front accessible USB 2.0 headers (USB 2/3, USB 4/5),
• Two (2) USB 3.0 ports on the rear I/O panel (USB 6/7)
• One (1) front accessible USB 3.0 header (USB 8/9)
• One (1) USB 3.0 Type-A header (USB 10)
BIOS
• 128Mb AMI BIOS
®
SPI Flash BIOS
• Real Time Clock wakeup, Play and Plug (PnP0, DMI 3.0, ACPI 4.0+, USB Keyboard and SMBIOS
Power Management
• ACPI Power Management
• Power / suspend-state indicator LED
• Main switch override mechanism
• Riser Card auto-detection
• Power-on mode for AC power recovery
• Keyboard Wakeup from Soft-Off
• CPU Fan auto-off in sleep mode
System Health Monitoring
• Onboard voltage monitoring for CPU core, CPU VCCIO power (0.95V), CPU VCCSA power (1.05V), memory power (1.2V),
chipset power (1.0V), BMC power (1.2V), +12V, +5V, +5V standby, +3.3V, +3.3V standby, and VBAT.
• CPU 3-phase switching voltage regulator
• CPU/System overheat LED and control
• CPU Thermal Trip support
• Thermal Monitor 2 (TM2) support
Fan Control
• Fan status monitoring with rmware 4-pin fan speed control via IPMI interface
• Low noise fan speed control
System Management
• Trusted Platform Module (TPM) support
• PECI (Platform Environment Control Interface) 2.0 support
• Node Manager Support (X11SSM-F only)
• IPMI View
• System resource alert via SuperDoctor® 5
• SuperDoctor® 5, Watch Dog, NMI
• Chassis intrusion header and detection
• Server platform service
