X11SSM(-F)/X11SSL(-F) User Manual

Note: The table above is continued on the next page.

Motherboard Features

CPU

• Intel® Xeon® E3-1200 v5 and 6th Gen Core™ i3, Pentium and Celeron processors in an LGA1151 (H4) socket. 80W

max TDP.

Memory

• Four (4) 288-pin DIMM slots support up to 64 GB of SDRAM 72-bit DDR4 unbuffered ECC 2133/1866/1600/1333MHz

memory

DIMM Size

• 16GB, 8GB, and 4GB, up to 64GB at 1.2V

Note 1: Memory speed support depends on the processors used in the system.

Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/

motherboard.

Chipset

• Intel® C236 PCH (X11SSM/-F)

• Intel® C232 PCH (X11SSL/-F)

Expansion Slots

• Two (2) PCI Express 3.0 x4in x8 slots (PCH slots 4 & 5) [slot 4 on X11SSM(-F) only]

• One (1) PCI Express 3.0 x8in x16 slot (CPU slot 6)

• One (1) PCI Express 3.0 x8 slot (CPU slot 7)

Network

• Intel i210 AT Gigabit Ethernet Controllers for LAN1/LAN2

Baseboard Management Controller (BMC)

• Aspeed AST 2400 Baseboard Controller (BMC) supports IPMI 2.0 (-F versions only)

• One (1) IPMI_dedicated_LAN located on the rear IO back panel (-F versions only)

Graphics

• Graphics controller via Aspeed AST2400 BMC

I/O Devices

• Serial (COM) Port

• One (1) serial port on the rear I/O panel (COM1)

• One (1) front accessible serial port header (COM2) (X11SSM/-F only)

• SATA 3.0

• Six (6) SATA 3.0 ports (I-SATA 0-5)

• Two (2) additional SATA 3.0 ports (I-SATA6-7) (X11SSM/-F only)

• Two (2) SuperDOM connectors (I-SATA0 & I-SATA1)

• RAID (PCH) • RAID 0, 1, 5, and 10

Motherboard Features
