B. DIAGRAM OF SPEEDOMETER
2
5
6
1
1
2
3
3
4
4
7
Speed
Temperature & distance
Display current speed
Display the temperature under
current operating conditions
Distance per charge/ trip distance/
rotating speed, ambient temperature
Total mileage
Controller temperature
7
Display current driving gear.
Gear Display
5
6
Display current battery power
level
Power display bar
Battery percentage display
Display the total mileage
Display the current battery power
percentage
