B. DIAGRAM OF SPEEDOMETER
M
Displacement switching Range/Temperature Change between KM/Mile and KM/P & MPH
M bottom instruction
Data connecting
Charging
NORMAL Mode ECO Mode
High beam indicator
Winker indicator light on
Battery error
Parking Light
Prompt fault code
M
DESCRIPTION OF COMPONENTS AND PARTS
In normal mode，press the switch for one second, turned into
force switch and keep the status.
Manually start the back light of Speedometer (Back light for
Letters + LCD back light)
In normal mode, press it longer than two seconds but shorter
than 8 seconds, start the back light for speedometer and
head light.
In normal mode, press it longer than 8 seconds, then release.
Press it less than 2 seconds, change indications, and keep
the status.
Press it longer than 2 seconds but shorter than 8 seconds,
start the back light for speedometer and head light.
Press it longer than 8 seconds, then release.
11
