b.BELT WEAR ANALYSIS
In the case of internal tooth crack(in the shape of hair):
In the case of out tooth crack:
In the case of missing tooth:
In the case of blurred core edge:
In the case of slight chipping:
In the case of blurred core edge:
In the case of edge damage due to stone:
In the case of the inclined exterior margin plane only:
Running under supervision;
Replace the belt;
Replace the belt
Running under supervision;
Running under supervision;
Running under supervision;
Replace the belt;
Running under supervision;
FAQ & TROUBLE SHOOTING
Error Causes Solutions
Please do not check the belt tension in cases that the belt is exposed to rain, cleaned in 24 hours or running in working tempera-
ture within 4 hours. Before belt tension testing, please allow the bike cool down to room temperature; if the belt has been running
over 5000 miles (8000 km) in damage or fault condition, please replace the belt and two chain wheels together. Attention: such
replacement needs a professional worker, please contact the service after sales or dealer.
28
