18
3 - Electrical Connections
3.3.6-F1 DOUBLE ACTION
DIGITAL/DIGITAL CONTROL OUTPUT
B
Cool
load
Static
Relay
20
21
OP6
Notes for pages 17 - 18 - 19
OP1 - OP2 Relay output
• SPST Relay N.O., 2A/250 Vac
(4A/120Vac)
for resistive load,
• Fuse 2A ac T at 250V, 4A ac T at 110V.
OP1 - OP2 Triac output
• N.O. contact for resistive load of up to
1A/250 Vac max.
• Fuse 1A ac T
Isolated digital outputs OP5-OP6
• 0…24Vdc, ±20%, 30 mA max.
Isolated analog outputs OP5-OP6
• 0/4…20mA, 750Ω / 15V max.
0/1…5V, 0…10V, 500Ω / 20mA max.
[1] Varistor for inductive load 24Vac only
3.3.6-E1 DOUBLE ACTION
DIGITAL/RELAY (TRIAC) CONTROL OUTPUT
B
3.3.6-E2 DOUBLE ACTION
ANALOG/RELAY(TRIAC) CONTROL OUTPUT
B
8
9
OP5
Heat
load
mA mV,V
Heat
load
Static
Relay
8
9
OP5
Fuse
Coil of the cool
load contactor
32
33
OP2
[1]
Fuse
Coil of the cool
load contactor
32
33
OP2
[1]
Heat
load
Static
Relay
8
9
OP5
