Super Systems 31095 - Operation: Input Menu; Input Menu Parameters

Menu
Tune
Yes
No
t.d.
t.i.
p.b.
tune
éno
for AT
OK
43
4 - Operation
4.4.4 PARAMETERIZATION
TUNING MENU (not shown for ON-OFF control action)
4.4.5 PARAMETERIZATION
INPUT MENU
Menu
InP
T.SaM
é 0:11
In.Sh
é 0
t.FiL
éOFF
Initial
tune start
(One shot tune)
no/yes
Calculated Proportional
band [1] (display only)
(available when adap-
tive tune is selected)
Calculated Integral
time [1] (display only)
(available when adap-
tive tune is selected)
Calculated derivative
time [1] (display only)
(available when adap-
tive tune is selected)
Filter time constant
(user enabled/disabled)
Off/0.2…99.9 seconds
Measure bias
-60…60 digit
Sampling time
0.1…10.0 seconds
Tuning
menu
Input
menu
[1] These values are not automatically stored on the PID
menu parameters
P.b.,t.i.,t.d.
