Super Systems 31095 - Operation: Communication Menu

PAr.y
bdr.S
é9600
énone
Add.S
é 1
PAr.y
é 3
Pro.S
bdr.S
é9600
éJbuS
Add.S
é 1
Pro.S
éJbuS
Add.P
é 3
Menu
CoMM
Depending on serial communication choosen (see model code
on page 5), there are the following parameters:
45
4 - Operation
4.4.7 PARAMETERIZATION - SERIAL COMMUNICATION MENU
SLAVE address
communication
(if option installed)
0ff / 1…247
SLAVE baud rate
1200/2400
4800
/9600/19200
SLAVE
communication protocol
MbuS / jbuS / SSIM
Parity
none/EVEn/odd
Index
c= 5
Index
c= 7-8
SLAVE address
communication
(if option installed)
0ff / 1…247
SLAVE baud rate
1200/2400
4800
/9600/19200
Communication
protocol
MbuS / jbuS
Parity
none/EVEn/odd
PROFIBUS DP
address
3…124
Serial
communication
menu
RS485 Modbus/Jbus
SLAVE
RS485 Modbus/Jbus
SLAVE + PROFIBUS DP
X5-SSI-uk 18-03-2009 17:54 Pagina 45
