Super SCC - Replacement Parts and Assemblies

■REPLACEMENT PARTS AND ASSEMBLIES
Q'ty(pc)
Part No.
Part Name and Assembly Name Part No./Assembly No. (Set No.)
Shackle
Bolt for Shackle
Cotter Pin
＊Nut for Shackle
Cam
Stop Ring
Shackle
1
1
1
1
1 set
1
1
1
1
1
SCH
SCCH
SCCN
SCCT
SCP
SCCP
SCCV
SCR
SCCR
SCCU
Pad
Screw
Pad
Hex. Hole Head Bolt
Nylon Nut
Screw
Handle
5
6
11
12
3
10
4
8
9
2
7
When ordering, specify the rated capacity (ton) of item No. (with "W" at the end in case
of wide type)
(Example : Screw for SCC3 is SCCR3)
(Example : Cam for SCC1W is SCCT1W)
Handle of SCC0.5 and SCC0.3W is ordered as an assembly, and the Assembly No. is
SCR0.5 (0.3W).
Periodic lubrication is required at cam holder and a sliding portion of Cam and Screw
(spherical portion).
1)
2)
3)
＊Only for SCC0.5 and SCC0.3W
Main body
12
