Super SCC - Shackle

Replace
Replace
Shackle
Ratedcapacity 
(ton)
0.3W 0.5 1 61.5 3 3W1W
13.5
9.5
16.5
13.5
9.5
16.5
15.5
11.5
23.5
19.5
15.5
27.5
19.5
15.5
27.5
23.5
18.5
32.5
23.5
18.5
32.5
34.5
31.5
52.5
D1(mm)
D2(mm)
W(mm)
Measure wear and
deformation at hole.
When the diameter of any one part of
circumference of hole (D1) exceeds the
respective size in the table below.
When the diameter of each part of
circumference of any hole becomes smaller
than respective size in the table below.
Bolt for
Shackle
Ratedcapacity 
(ton)
Diameter
(mm)
0.3W
11.5
0.5
11.5
1
13.5
6
32.5
1.5
17.5
3
21.5
3W
21.5
1W
17.5
When the diameter of any one part of
circumference of bolt shank becomes smaller
than the respective size in the table below.
When damaged, loosening or missing.
Measure wear at shank.
Visually check for deformation.
Inspection method Limit of use Remedy
Item
Replace
Replace
Cotter
Pin
Visually check for the
attached condition.
When damaged or missing.
Nut for
Shackle
SCC0.3W
SCC0.5
Visually check for the
installed condition.
When damaged, loosening or missing.
20
