Super SJC - Clamp Operation and Method of Use; Screw and Cam Engagement Method; Setting Clamp for Lifting Operations

13
The screw will tighten when turned clockwise, and will loosen when terned
counterclockwise.
Thecamwillretreatabout3mmaftercomingintocontactwiththesteelplate
whentightningthescrew.Continuetotightenthescrewuntilthecamisfirmly
in contact with the steel plate.  The tightening torque of the screw must
exceed25N･m(about250Kgf･cm).
Whensettingtheclamp,inserttheobject tobeliftedcompletelyintothejaw
openinguntilitcomesintocontactwiththedeepestsection.Tightenthescrew
firmlytillallsectionsoftheinnercamtoothringcomeintosquarecontactwiththe
objecttobelifted.
1.OPERATION METHOD
1）
2）
3）
The cam will retreat
about3mm
(becomenarrower)
All sections of the inner
cam toothring in square
contactwiththe objectto
belifted.
Tighteningtorque：
over25N・m
Cam
Objecttobelifted
Screw
Clampsettoposition
andnotunderaload
Whenunderaload
Theclampingbiteisbigger
Inserttheobjecttobelifted
completelysoitcomesinto
contactwiththedeepestsection.
■How to use
