Part Reference Chart
Part
No.
Description Material
Part
No.
Description Material
1 Pump 29 Cartridge Bag PP
2 Base FRP 29 Star Cloth Bag PP / PO
3 Barrel Base FRPP 30 Cartridge Nut
FRPP /
PVDF
4 Barrel PP 31 Stanchion SUS316
5 * C-Clasp FRPP 32 Stanchion Nut SUS316
6 Cover Packing
NBR / EPT /
VITON
33 Cartridge Plate FRPP
7 Cover FRPP 34 Cartridge Spring
SUS316 /
PVC
8 Tube PP 35 Cartridge Top Packing
FRPP /
PVDF
9 Tube Base FRPP 36 Activated Carbon Cage FRPP
10 Tube Valve PP 37 Start Frame FRPP
11 Tee inlet with valve FRPP 38 Solution Collector FRPP
12 Outlet FRPP 39 Star Seat FRPP
13 Power Switch with case FRPP 39-1 Star O-Ring
NBR / EPT /
VITON
14 Pressure Gauge 40 Filter Frame Nut FRPP
15 Pressure Gauge Seat FRPP 41 Star Stanchion SUS316
15-1
Pressure Gauge
Diaphragm
NBR / EPT /
VITON
42
Filter Medium Bottom
Packing
NBR / EPT /
VITON
16 Air Release Joint FRPP 43 Star Fasten Handle FRPP
17
Air Release Joint Seat
with Gasket
FRPP 45 Paper Center Tube PP
18 Air Release Pipe FRPP 47 Upper Disk set Cover FRPP
19 Air Release Valve FRPP 48 Lower Disk set Cover FRPP
19-1
* Air Release Handle
Spacer Packing
NBR / EPT /
VITON
49 Disk (20 pcs / set) FRPP
20 Cartridge PP 50 Paper (100 pcs / box) PP
21 Cartridge Bottom Packing PVC / PP 51 Disk bottom O-Ring
NBR / EPT /
VITON
22 Cartridge Seat FRPP 52 Star Frame small Hoop PP
22-1 Cartridge Seat O-Ring
NBR / EPT /
VITON
53 Star Frame Hoop Nut PP
23
SUS Clamp (excluding
screw)
SUS304 54 Star Frame big Hoop PP
24 Cover Screw SUS304 55 Upper Disk set Base FRPP
25 Cover Washer SUS304 56 Lower Disk set Base FRPP
26 Cover Handle FRPP 57 Disk Top O-Ring
NBR / EPT /
VITON
27 Drain Valve PP 60 Bag PP
28 Barrel Base O-Ring
NBR / EPT /
VITON
61 Basket PP
62 Bag Fasten Handle PP
* is for old construction.
